Unlocking 7-Segment Display Magic with Arduino

Seven-Segment Display (SSD)

Interfacing an Arduino with a 7-segment display is like teaching your microcontroller to count—literally! These displays are made up of seven LEDs (plus sometimes a sneaky eighth for the decimal point), arranged in a figure-eight. By toggling different segments on or off, you can display numbers from 0 to 9 (and a few rebellious letters). When you connect it to an Arduino, you’ll use digital pins to control each segment. It’s like choreographing a light show, but instead of disco, it spells out... numbers. Perfect for digital clocks, counters, or impressing your pet hamster with basic math. Now, let’s wire it up! You can use a common cathode or common anode display—think of them as the “introverts” and “extroverts” of the LED world. With a little help from resistors (don’t skip them unless you enjoy the smell of burning plastic), you’ll connect each segment to an Arduino pin. Then comes the fun part: programming! With a simple sketch, you can loop through digits, build a stopwatch, or display “07734” (turn your head and thank your childhood calculator). Interfacing a 7-segment display with Arduino is an electrifying way to learn basic electronics and coding—literally lighting up your STEM journey!

Segment Arrangement

Each segment is controlled independently and can be turned ON or OFF to form the desired digit.

Arrangement

A
F      B
 G
E      C
D   DP

Types of Seven-Segment Displays

Common Anode (CA)

  • To turn ON a segment, apply a LOW (0V) signal.
  • To turn OFF a segment, apply a HIGH (Vcc) signal.

Common Cathode (CC)

  • To turn ON a segment, apply a HIGH (Vcc) signal.
  • To turn OFF a segment, apply a LOW (0V) signal.

Requirements

Pin Configuration of Seven-Segment Display

Common Anode (CA) Configuration

  • The Vcc pin (common anode) is connected to +5V or a HIGH signal.
  • Individual segments light up when connected to ground (LOW/0).

Common Cathode (CC) Configuration

  • The Gnd pin (common cathode) is connected to ground (0V).
  • Individual segments light up when connected to +5V or a HIGH signal.

Encoding of Digits (Common Cathode)

Algorithm

  1. Initialize Components

    • Select the type of seven-segment display (Common Anode or Common Cathode).
    • Identify the segment pins (a, b, c, d, e, f, g, dp) and connect them to the Arduino digital I/O pins.
    • If using a Common Anode display, connect the common pin to +5V.
    • If using a Common Cathode display, connect the common pin to GND.

  2. Define Pin Connections

    • Assign each segment pin to an Arduino digital output pin.
    • If required, connect a current-limiting resistor (220Ω - 470Ω) in series with each segment to prevent excessive current.

  3. Configure Arduino Pins

    • Set all segment control pins as OUTPUT in the setup () function.

  4. Define Display Patterns

    • Create an array of binary patterns to represent numbers (0-9) for the seven-segment display
    • Each bit in the pattern corresponds to an LED segment (ON/OFF).

  5. Write the Display Function

    • Create a function that takes a number (0-9) as input and activates the corresponding segments..
    • If using a Common Anode display, write LOW to turn ON segments.
    • If using a Common Cathode display, write HIGH to turn ON segments.

  6. Display Numbers Sequentially

    • Use a loop to display numbers 0-9 with a small delay between each.

  7. Repeat or Modify as Needed

    • Continuously display numbers or modify the program for a specific application (e.g., counters, timers).

Arduino Code

1 // Arduino 7-Segment Display: Wiring & Code Guide
2// This code displays digits from 0 to 9 on a common cathode 7-segment display
3
4// Define segment pins connected to Arduino
5int a = 2;
6int b = 3;
7int c = 4;
8int d = 5;
9int e = 6;
10int f = 7;
11int g = 8;
12
13void setup() {
14  // Set all segment pins as OUTPUT
15  pinMode(a, OUTPUT);
16  pinMode(b, OUTPUT);
17  pinMode(c, OUTPUT);
18  pinMode(d, OUTPUT);
19  pinMode(e, OUTPUT);
20  pinMode(f, OUTPUT);
21  pinMode(g, OUTPUT);
22}
23
24// Function to display a digit (0–9) on the 7-segment display
25void displayDigit(int digit) {
26  switch (digit) {
27    case 0:
28      digitalWrite(a, HIGH);
29      digitalWrite(b, HIGH);
30      digitalWrite(c, HIGH);
31      digitalWrite(d, HIGH);
32      digitalWrite(e, HIGH);
33      digitalWrite(f, HIGH);
34      digitalWrite(g, LOW);
35      break;
36    case 1:
37      digitalWrite(a, LOW);
38      digitalWrite(b, HIGH);
39      digitalWrite(c, HIGH);
40      digitalWrite(d, LOW);
41      digitalWrite(e, LOW);
42      digitalWrite(f, LOW);
43      digitalWrite(g, LOW);
44      break;
45    case 2:
46      digitalWrite(a, HIGH);
47      digitalWrite(b, HIGH);
48      digitalWrite(c, LOW);
49      digitalWrite(d, HIGH);
50      digitalWrite(e, HIGH);
51      digitalWrite(f, LOW);
52      digitalWrite(g, HIGH);
53      break;
54    case 3:
55      digitalWrite(a, HIGH);
56      digitalWrite(b, HIGH);
57      digitalWrite(c, HIGH);
58      digitalWrite(d, HIGH);
59      digitalWrite(e, LOW);
60      digitalWrite(f, LOW);
61      digitalWrite(g, HIGH);
62      break;
63    case 4:
64      digitalWrite(a, LOW);
65      digitalWrite(b, HIGH);
66      digitalWrite(c, HIGH);
67      digitalWrite(d, LOW);
68      digitalWrite(e, LOW);
69      digitalWrite(f, HIGH);
70      digitalWrite(g, HIGH);
71      break;
72    case 5:
73      digitalWrite(a, HIGH);
74      digitalWrite(b, LOW);
75      digitalWrite(c, HIGH);
76      digitalWrite(d, HIGH);
77      digitalWrite(e, LOW);
78      digitalWrite(f, HIGH);
79      digitalWrite(g, HIGH);
80      break;
81    case 6:
82      digitalWrite(a, HIGH);
83      digitalWrite(b, LOW);
84      digitalWrite(c, HIGH);
85      digitalWrite(d, HIGH);
86      digitalWrite(e, HIGH);
87      digitalWrite(f, HIGH);
88      digitalWrite(g, HIGH);
89      break;
90    case 7:
91      digitalWrite(a, HIGH);
92      digitalWrite(b, HIGH);
93      digitalWrite(c, HIGH);
94      digitalWrite(d, LOW);
95      digitalWrite(e, LOW);
96      digitalWrite(f, LOW);
97      digitalWrite(g, LOW);
98      break;
99    case 8:
100      digitalWrite(a, HIGH);
101      digitalWrite(b, HIGH);
102      digitalWrite(c, HIGH);
103      digitalWrite(d, HIGH);
104      digitalWrite(e, HIGH);
105      digitalWrite(f, HIGH);
106      digitalWrite(g, HIGH);
107      break;
108    case 9:
109      digitalWrite(a, HIGH);
110      digitalWrite(b, HIGH);
111      digitalWrite(c, HIGH);
112      digitalWrite(d, HIGH);
113      digitalWrite(e, LOW);
114      digitalWrite(f, HIGH);
115      digitalWrite(g, HIGH);
116      break;
117  }
118}
119
120void loop() {
121  // Loop through digits 0 to 9
122  for (int i = 0; i <= 9; i++) {
123    displayDigit(i);
124    delay(1000); // Wait for 1 second
125  }
126}
127

Applications of Seven-Segment Displays

  • Digital clocks
  • Calculators
  • Electronic meters (e.g., voltmeters, ammeters)
  • Fuel pumps
  • Industrial control panels
  • Scoreboards and counters

Conclusion
